SWITCH
Easy-To-Deploy Survey Companion
The SWITCH provides evolved surveying technology with familiar user operation. The most user-friendly single-shot and multi-shot surveyor in one tool.
Features and Benefits
-
Measure local gravity, total mag field strength and magnetic dip angle
-
Determine borehole inclination and azimuth
-
Collect gravity high-side and magnetic tool face orientation data
-
Retrieve G-total vibration data
-
And more additional QC parameters displayed
With the push of a button, the SWITCH will get you up and running in minutes.
Download SWITCH Flyer
INSTRUMENT ACCURACY
| Inclination |
+/- 0.1° |
| Azimuth |
+/- 0.5° (Inc. >10°, Dip <70°) |
| Toolface |
+/- 0.1° |
OPERATING FEATURES
| Instrument O.D. |
1.0” |
| Instrument Length |
43” (with timer unit) |
| Digital Interface |
Serial RS 232 compatible |
| Data Storage |
Calibration data only |
| Parameters Sampled |
Gx,y,z, Bx,y,z, Temp, Battery volts |
| Data Outputs |
Inclination, Azimuth, Magnetic Toolface, Gravity Toolface, Magnetic Field Strength, Gravity Totals, Dip Angle, Temperature, Battery Volts (raw and corrected survey data can be read from the on-board display and/or computer) |
ELECTRICAL
| Voltage Supply |
9 VDC (6 AA alkaline batteries) |
| Max. Power Consumption |
.2 Watts (2mW standby) |
SENSORS
| High accuracy triaxial magnetometers |
| High accuracy accelerometers (triaxial) |
| Temperature |
ENVIRONMENTAL
| Temperature |
0-200°C (with standard running gear thermoshielded) |
| Shock |
1000g, ½ sine 3mS |
| Vibration |
5-25 Hz rms 1″ (double amplitude) |
|
25-500 Hz, 20g (all axes) |
COMPUTER SYSTEM REQUIREMENTS
| Windows Operating System |
Windows 2000, XP, Vista & Windows 7 |
| RS-232 Communication Port |
Data Transfer 115 Kbps |
RUNNING GEAR
| Standard Running Gear |
1.75″ O.D. with internal heat shield |
| Optional Running Gear |
1.375″ O.D. unshielded |
